OrgaLED® PCB Deco

Features

  • Binning +/- 50
  • Dimmable
  • Osram LEDs
  • Effective heat dissipation
  • Life > 50,000 hours (LM79)
  • Very flexible (bend radius > 1.2″)
  • 66′ run lengths Mono

OrgaLED PCB Deco

The OrgaLED® PCB Deco LED strip (IP20) is a flexible LED strip equipped with 3M double sided tape without the unique co-extrusion technology. The OrgaLED® PCB Deco LED strip is ideal to use in small indoor spaces. Indoor use only.
TemperatureColorOutputWattageRun LengthDimensionPart Number
2400K27 lm/ft0.33 W/ft65.6 ft0.31 x 0.043 in012197
2700K32 lm/ft0.33 W/ft65.6 ft0.31 x 0.043 in012174
3000K31 lm/ft0.33 W/ft65.6 ft0.31 x 0.043 in012180
4000K34 lm/ft0.33 W/ft65.6 ft0.31 x 0.043 in012186
6500K34 lm/ft0.67 W/ft65.6 ft0.31 x 0.043 in012185
RGB 16048 lm/ft1.4 W/ft33 ft0.31 x 0.039 in012187
Red16 lm/ft1.3 W/ft65.6 ft0.31 x 0.09 in012182
Green41 lm/ft0.7 W/ft65.6 ft0.31 x 0.09 in012183
Blue8 lm/ft0.5 W/ft65.6 ft0.31 x 0.09 in012184
Amber12 lm/ft1.3 W/ft65.6 ft0.31 x 0.09 in012181

Accessories

OrgaLED® Diffuse offers a range of Mirror Welded IP69 connections to suit your every need.

Power Supplies

24V DC; 0-10V and Magnetic Power Supplies options ranging from 25W-300W.

Mounting & Extrusions

Mounts directly with brackets, self adhesive transparent channels, or in aluminum extrusions.
