Features
- Binning +/- 50
- Dimmable
- Osram LEDs
- Effective heat dissipation
- Life > 50,000 hours (LM79)
- Very flexible (bend radius > 1.2″)
- 66′ run lengths Mono
OrgaLED PCB Deco
The OrgaLED® PCB Deco LED strip (IP20) is a flexible LED strip equipped with 3M double sided tape without the unique co-extrusion technology. The OrgaLED® PCB Deco LED strip is ideal to use in small indoor spaces. Indoor use only.
Temperature | Color | Output | Wattage | Run Length | Dimension | Part Number |
---|---|---|---|---|---|---|
2400K | ![]() | 27 lm/ft | 0.33 W/ft | 65.6 ft | 0.31 x 0.043 in | 012197 |
2700K | ![]() | 32 lm/ft | 0.33 W/ft | 65.6 ft | 0.31 x 0.043 in | 012174 |
3000K | ![]() | 31 lm/ft | 0.33 W/ft | 65.6 ft | 0.31 x 0.043 in | 012180 |
4000K | ![]() | 34 lm/ft | 0.33 W/ft | 65.6 ft | 0.31 x 0.043 in | 012186 |
6500K | ![]() | 34 lm/ft | 0.67 W/ft | 65.6 ft | 0.31 x 0.043 in | 012185 |
RGB 160 | ![]() | 48 lm/ft | 1.4 W/ft | 33 ft | 0.31 x 0.039 in | 012187 |
Red | ![]() | 16 lm/ft | 1.3 W/ft | 65.6 ft | 0.31 x 0.09 in | 012182 |
Green | ![]() | 41 lm/ft | 0.7 W/ft | 65.6 ft | 0.31 x 0.09 in | 012183 |
Blue | ![]() | 8 lm/ft | 0.5 W/ft | 65.6 ft | 0.31 x 0.09 in | 012184 |
Amber | ![]() | 12 lm/ft | 1.3 W/ft | 65.6 ft | 0.31 x 0.09 in | 012181 |
Accessories
OrgaLED® Diffuse offers a range of Mirror Welded IP69 connections to suit your every need.
Power Supplies
24V DC; 0-10V and Magnetic Power Supplies options ranging from 25W-300W.
Mounting & Extrusions
Mounts directly with brackets, self adhesive transparent channels, or in aluminum extrusions.
